BELIMO RetroFIT
2*AFBUP-X1
Electrical data
| Nominal voltage | AC 24...240 V / DC 24...125 V |
| Nominal voltage frequency | 50/60 Hz |
| Nominal voltage range | AC 19.2...264 V / DC 21.6...137.5 V |
| Power consumption in operation | 7 W |
| Power consumption in rest position | 3.5 W |
| Transformer sizing | 36 VA |
| Electrical Connection | 18 GA appliance cable, 3 ft [1 m], with 1/2" NPT conduit connector |
| Overload Protection | electronic thoughout 0...90° rotation |
Functional data
| Direction of motion motor | selectable by ccw/cw mounting |
| Direction of motion fail-safe | reversible with cw/ccw mounting |
| Manual override | 5 mm hex crank (3/16" Allen), supplied |
| Angle of rotation | 95° |
| Running Time (Motor) | 75 s / 90° |
| Running time fail-safe | <20 s |
| Noise level, motor | 50 dB(A) |
| Noise level, fail-safe | 62 dB(A) |
| Position indication | Mechanical, 30...65 mm stroke |
